Standard technical features:

• 16-channel analog audio input 16-channel analog audio output, support free switching of microphone input and line input.
• 4 channel Dante network in option.
• Built-in white noise, pink noise, sine wave three different test signal sound sources, can be used as various systems to detect sound sources.
• Support 9 level sensitivity adjustment for each mic input channel. Supports 48V phantom power, adapts to various types of condenser microphones.
• Support matrix mixing, free setting, each channel of mixing can also independently adjust the mixing volume, matching gain is more convenient, intuitively viewing and debugging signal routing.
• Support AUTO MIX shared gain type automatic mixing, each channel is adjusted independently, 10 priority gears, the slope and response time can be adjusted, and the automatic switching between microphones, microphones and music signals, and music signals is realized. Good reduce noise, improve signal-to-noise ratio, and reduce howling.
• Support AFC active feedback suppression function, two-speed adjustment.
• Support ANC adaptive active noise control function, 4-level intensity adjustment, to meet the local recording and broadcasting needs of different scenes, improve the signal-to-noise ratio of recording and amplification, and record clearer voice signals.
• Support AEC adaptive acoustic echo control function, 6-level tail length effect adjustment, suitable for interactive recording and broadcasting remote meetings and teaching applications in various large and small occasions, restoring clearer voice communication.
• With Echo and Reverb effect function, it can add the effect state to the hard vocal, presenting a more emotional vocal effect; it can also meet the singing entertainment application without additional equipment.
• Input with 31 bands PEQ adjustable, output with 10 bands PEQ adjustable, with high and low shelf and all-pass filter, both input and output are equipped with 48-step high and low pass frequency divider, the adjusted parameters can be saved in independent channels or copied to other channels, which is convenient Adjust the sound system in all directions.
• Camera tracking control function, configure RS232/485 interface, support camera control PELCO-D/PELCO-P/VISCA and other protocols.
• Support preset and lock to ensure project stability.
• USB drive-free automatic connection software, support TCP/IP centralized management and debugging of multiple machines, configure RS232, RS485 central control interface, the software comes with central control protocol, convenient for users to find, support GPIO external expansion control interface.
• Windows system self-installing software Mconsole unified management, Android APP TCON wireless network control.
• Optional 4-inch touch screen wire control box control.
